The special task charger
Enelion Wallbox allows you to charge with 22kW. Equipped with a Type2 charging socket and RFID reader it can be part of a charging station network with up to 90 Enelion devices. The OLED display shows instructions and charging details in the selected language.
Enelion charging stations can be equipped with a Bridge communication module, a certified MID meter, additional residual current protection type B and DLB functionality.
Two colors of anodized aluminum
The housing is made of anodized aluminum and is available in two colors: silver and graphite-black. The front of the device is made of hardened plastic to increase protection against scratches.
The charger is equipped with a graphic display made with the OLED technology. It allows the user to get all the information necessary for quick charging process. It’s especially useful in publicly accessible devices.
Check the charging status, control the energy usage, be on top of the situation.
Advanced LED signalling
The Enelion team worked hard on making the status LEDs of the charger intuitive and aesthetically pleasing. Using the unlimited pallette of colours and advanced animation allows you to recognize whether the charger is available, charging or reserved.
Our device always reacts to your actions, so You’ll never get confused.
Socket with a lock
For maximum compatibility with existing electric vehicle the device is eqiupped with a Type 2 socket. That allows the user to utilize their own charging cable.
Advanced lock management allows for either maximum security or maximum comfort.
Materials such as anodised aluminium allow us to be sure that our devices look good even after many years of service in challenging atmospheric conditions.
Power set to your needs
Enelion chargers were created to satisfy the needs of our clients. That’s why we never limit their capabilities. Each charging terminal may be configured to work in a one-phase or three-phase network. The charging current ranges from 6 to 32 amperes. Your dealer will help you with configuration of these settings.
Power from 1.4 to 22 kW. Just as you need it!
Introduce yourself with RFID
Integrated RFID reader allows for user recognition. Well established Mifare card technology provides the capability of user access management.
Use the Offline Card Groups and provide your users with an access to many chargers without connecting them to the Internet.
To use the charger in your own home disable the RFID to begin charging immediately after plugging in (Plug&Charge mode).
Touch to change
Touch buttons complete the Enelion charger interface. Use them to change charger settings, browse statuses or switch the language.
RCM B Protection
Local regulations stipulate that one must use protection against direct current leaks. To avoid a costly purchase of a differential current protection switch of type B (1000 PLN and more) choose the optional Enelion Rcm B module.
Built in energy measurement
Enelion uses a custom system of energy measurement. This allows for the usage of advancent power management algorithms.
Learn about Enelion DLB* and its benefits.
If you need a certified measurement for energy bill settlement ask about Enelion MID.
Enelion Bridge – bridge to new possibilities!
User expectations are constantly rising. To meet them we have created Enelion Bridge! It’s a module that provides Smart capabilities to a charger and all benefits of Online via OCPP1.6.
See what you can get with Enelion Bridge!
See what happens when you connect your charger to the Internet and a administration system such as Enelink.
Chain to achieve more
Enelion charging terminals are useful in all circumstances and applications thanks to their wide range of connection capabilities.
Enelion created Enelion Chain allowing the chargers to:
- Cooperate using Enelion DLB,
- Use the Smart functionality with only one Enelion Bridge,
- Connect to Enelion Energy Guard,
- Allow all charging points to come Online,
- and much more…
Learn about Enelion DLB and its benefits.
